2025 RZR Trail Sport
Exterior Color
Zenith Blue
LEGEND:
S = Series O = Optional
Brakes
S
Parking Brake - Park In-Transmission
S
Front/Rear Brakes - 4-Wheel Hydraulic Disc with Dual-Bore Front and Rear Calipers
ENGINE/DRIVETRAIN
S
Fuel System/Battery - Electronic Fuel Injection
S
Transmission/Final Drive - Automatic PVT P/R/N/L/H
S
Drive System Type - True On-Demand AWD/2WD
S
Cylinders Displacement - 875cc
S
Engine Type - 4-Stroke DOHC Twin Cylinder
S
Cooling - Liquid
S
Horsepower - 75 HP
S
Engine Braking System (EBS)
Dimensions
S
Bed Box Dimensions (L x W x H) - 20.7 x 37 x 7.9 in (52.5 x 94 x 20 cm)
S
Wheelbase - 79 in (200.7 cm)
S
Ground Clearance - 11 in (27.9 cm)
S
Box Capacity - 300 lb (136 kg)
S
Fuel Capacity - 9.5 gal (35.9 L)
S
Hitch Towing Rating - 1,500 lb (680 kg)
S
Estimated Dry Weight - 1238 lb (561.5 kg)
S
Overall Vehicle Size (L x W x H) - 110.9 x 50 x 67.9 in (282 x 127 x 172.5 cm)
S
Payload Capacity - 740 lb (335.7 kg)
Tires/Wheels
S
Wheels - Stamped Steel
S
Rear Tires - 26 X 9 X 12
S
Front Tires - 26 X 8 X 12
Additional Specifications
S
Cargo System - Lock & Ride
S
Electronic Power Steering
S
Other Standard Features - Adjustable Tilt Steering
S
Doors - Full Doors
S
Hitch Type - Standard 1.25 in (3.2 cm) Receiver
S
Lighting - White LED Low/High & Red LED Tail/Brake Lights
S
Instrumentation - Dual-Sweep Analog Dials with 4" LCD Rider Information Center: User Selectable Blue/Red Backlighting & Brightness, Programmable Service Intervals, Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seat Belt Reminder Light, Gear Indicator, DC Outlet + 12V Power Plug
S
Seat Type - Bolstered Bucket Seats with Toolless Driver Seat Slider and Standard Passenger Seat Slider (Tool Required for Adjustment on Passenger Seat)
Suspension
S
Front Shocks - ZF Sachs
S
Front Suspension - Dual A-Arm with Stabilizer Bar and 10" (25.4 cm) Wheel Travel
S
Rear Shocks - ZF Twin Tube
S
Rear Suspension - Dual A-Arm with Stabilizer Bar and 10 in (25.4 cm) Wheel Travel
